1

1” BSP – 17 JIC Elbow ZP

208-2-0059

3

2

Lubrication Hose Assy: Actuator to Pump

SAPH-017

1

3

Lubrication Hose Assy: Actuator to Pump

SAPH-016

1

4

1/8” Hex Head Plug Stainless Steel

202-6-0005

3

5

Sight Glass

500-21-0016

2

6

Lubrication Hose Assy: HE to Actuator

SAPH-019

1

7

Cooling Hose Assy: HE to Drain

SAPH-002

1

8

Lubrication Hose Assy: Filters to HE

SAPH-010

1

9

Cooling Hose Assy: Sol Valve to HE

SAPH-001

1

10

Ball Valve, ¾” BSP M/F

203-18-0036

4

11

1 ¼” – ¾” Reducing Bush

203-9-1210

6

12

1 ¼” BSP Female Tee

208-5-0001

2

13

¾” Plug

203-6-0750

1

14

1 ¼” Nipple

203-4-1250

3

15

Oil Filter Moisture Absorption 19µm

500-19-0057S

1

16

5.1” Filter Head

500-19-0055

2

17

Oil Filter Z-Glass Media 4µm

500-19-0056S

1

18

¾” BSP – 17 JIC Nipple

208-4-0073

3

19

1 ¼” BSP M/F Elbow

208-2-0057

1

20

¾” BSP – 17 JIC 45 Elbow ZP

208-4-0080

1

21

Heat Exchanger – 120 Plate

500-18-0098

1

22

¾” BSP – 17 JIC Elbow SS - Modified

208-2-0058-1

2

23

1 ¼” BSP – 17 JIC Nipple

208-1-0002

1

24

¾” BSP – 12 JIC Elbow SS - Modified

208-2-0052-1

1

25

Clamp Plate

SPS-08-3

1

26

M6 All Thread, 330mm

102-20-0330

4

27

½” BSP – 12 JIC Nipple

208-4-0081

1

28

½” Bulkhead

209-29-0010

2

29

½” BSP – 17 JIC Nipple

208-4-0082

1

30

½” Diaphragm Valve

205-17-0030

1

31

½” Nipple

203-4-0500

1

32

Lubrication Hose Assy: Pump to Filters

SAPH-018

1

33

¾” Strainer

203-11-0750

2

34

¾” BSP M/F Elbow

203-2-0030

2

35

1 ¼” – ¾” Male Reducer

203-8-0020

2

36

1” NPT – 1 ¼” BSP Nipple

208-4-0087

1

37

Oil Pump (1”)

500-7-0108

1

38

1” NPT – 17 JIC Elbow

208-2-0048

1

NA

Oil pump seal kit (1”)

500-7-0093

1

NA

Oil pump repair kit dual

500-7-0094

1

NA

Techni Syn-Gear EP150 20L Drum

500-3-0017

2

1

Normally Open Actuator

13243

1

2

Stem-HP Valve

11102

1

3

Backup ring

12733

1

4

Brass Backup Ring/HP Valve

11104

1

5

Seal-HP Valve

11100

1

6

Valve Body

11320

1

7

Valve Seat

11099

1

8

Adaptor M/F

13802

1

Repair kit On/Off valve

12967

1

1

PISTON, N.O. VALVE ACTUATOR

13302

1

2

HOUSING, N.O. VALVE ACTUATOR

13303

1

3

CAP, N.O. ACTUATOR

13304

1

4

-035 O RING BUNA

11679-035

2

5

O RING, 70 DURO, -143

11679-143

1

1

HP Guard

SAP-G4-58

2

2

HMI Front Panel

SAP-G4-52

1

3

Back Panel

SAP-G4-53

1

4

Frame Assembly

SAP-G4-10-2

1

5

Side Door Assembly

SAP-G4-218

2

6

Fan Filter Element – 120mm

700-2-0116

1

7

Fan Guard Louvered – 120mm

700-2-0114

2

8

Service Panel

SAP-G4-45

1

9

Door Panel

SAP-G4-59

1

10

Lift off Hinge LH

500-10-0065

2

11

Fixed Knuckle

500-13-0032

2

12

Adjustable Feet

500-13-0030

4

13

Seal Removal Tool – 17.5mm

SPT-07

1

14

Shadow Board

SAP-G4-37

1

15

Finger Guard – 120mm

700-2-0109

3

16

Fan – 120mm

700-2-0113

3

17

Actuator Stand

SAP-G4-51

2

18

Front Cover

SAP-G4-19

1

19

Top Cover

SAP-G4-38-1

1

20

E-stop Assembly

700-4-0041

1
